Echandia Core
LTO system up to 1,500 V and 3C; 70,000 cycles at 70% DoD; company claims 30% lower cost and footprint.
Echandia Core was launched in June 2026 as the company's balanced LTO system. It supports high-voltage configurations up to 1,500 V, which Echandia says is unique in the marine battery market. It is rated for 3C charge and discharge and 500 A per string, and for 70,000 cycles at 70% depth of discharge, with 90% usable capacity. Echandia claims about 30% lower cost and 30% smaller footprint than its previous system, for operations of 5 to 10 cycles per day.
Specifications
- Voltage v max
- 1,500
- C rate
- 3
- Current a per string
- 500
- Cycle life 70pct dod
- 70,000
- Usable capacity pct
- 90
- Chemistry
- LTO
- Fuels
- electric
