Kumera propulsion gearboxes

Name: Kumera propulsion gearboxes
Brand: Kumera Marine

Propulsion / hybrid gearbox · Type 200–Type 450 and larger; hybrid PTI/two-input gearboxes

CPP reduction gearboxes with built-in pitch servo and PTO/PTI options, plus hybrid two-input and in-line gearboxes.

Kumera's standard CPP gearboxes are named by the centre distance between input and output shafts, for example Type 200 (100–350 kW) up to Type 450 (500–2,000 kW) and larger. Across eight models the range covers 100–5,000 kW with ratios from 2:1 to 7:1. Features include a built-in hydraulic servo for pitch control, multiple PTOs/PTIs, DNV type approval, and optional two-speed operation and condition monitoring. Hybrid versions include two-input, PTI and in-line designs.

Specifications

Power kW min: 100
Power kW max: 5,000
Reduction ratio: 2:1-7:1
